SSL BTC 20 Beam Tester Camera

Quality Control System for Angular Luminous Intensity Patterns

/ SOLUTIONS / BEAM TESTER CAMERA

Beam Testing Camera System SSL BTC 20 is a camera based setup for fast yet reproducible beam pattern measurements of directional light sources such as automotive and flashlight sources. The typical measurement time is 5 - 10 seconds.  BTC 20 produces comparable results to turning goniophotometers with an accuracy of 7 %. The dynamic measurement range is from 0.3 cd up to 70 000 000 cd.

The main part of the setup is a carriage with the camera, a luminaire holder and the operating computer. There are two lasers for correct alignment of the luminaire. The carriage can be taken aside to save floor space when the measurements are not ongoing. The ceiling height of the laboratory room needs to be at least 2.5 m and the ceiling, the walls and the floor need to be low-reflecting and dark.

SSL BTC 20 is a good choice for characterizing essential photometric parameters of automotive lighting fixtures and portable flashlights. Other popular application is testing of spot lamps in the connection of the assembly line of the lighting fixtures.

Measurement parameters:

  • Beam pattern
  • Axial luminous intensity
  • Maximum luminous intensity
  • Beam distance
  • Isolux curves on the road surface and vertical plane
  • Isolux curves on the horizontal level at luminaire height
  • Partial luminous flux and efficacy
  • ANSI/NEMA FL 1-2009 test routines to measure
  • beam distance
  • maximum beam intensity
  • runtime of photometric performance of flash lights.

Options:

  • Input power measurement
  • Spatial color parameters
  • Turning axis for vertical plane
Datasheet - SSL BTC 20
Request a quote
SSL BTC 20 in daily use at Valostore Valolab
